Air System: Viair Expedition High Pressure OBA

Photo By: Viair

Appealing to the avid overlander, Viair’s Expedition High-Pressure OBA gets to work at 200 PSI from a 2.5-gallon tank. It’s powered by a 100% duty 444C — a tough, reliable unit wildly popular in the demanding world of air suspension.

Image by Viair

Apart from fast tire inflation rates on tires up to 37 inches in diameter, this performance combo allows it to run air tools, pop beads, setup inflatables, and a whole array of pneumatic tasks, including air lockers and load levelers. The system can be monitored and activated from the driver’s seat using the dash panel gauge, crouch-free tire inflation is made possible via a 40-inch hose with digital tire gun combo, and a blow gun gets all cleaning tasks done.

READ MORE: Overland Expo’s Ultimate Overland Vehicle 2022

This kit comes with all accessories needed for installation with a mounting bracket, tank port fittings kit, compression fittings, coupler, stud, and enough airline to relocate the air filter and make sure the air outlet can be mounted wherever is most convenient. In terms of electrical, it includes a sealed relay and pressure switch, ANL fuse holder for up to 6-gauge wires, and 20 feet of 12-gauge wire to connect the dash panel gauge.

This is a great product for those who get out often and want a capable, versatile onboard air kit.

Image by Viair

What to Know:

  • 12-Volt
  • Permanent Magnetic Motor
  • Duty Cycle: 100% @ 200 PSI
  • Max. Working Pressure: 200 PSI
  • Max. Air Tank Size: 5.0 Gallon
  • Max. Amp Draw: 23-Amps
  • Ingress Protection Rating: IP67
  • Dimensions: 10.63″L x 4.1″W x 6.44″H
  • Net Weight: 11.10 lbs
  • MSRP: $659.95
